KerbDrain E/E+

Award winning combined kerb and drainage system

It is crucial to divert surface water away from roads and highways in order to minimise the risk of flooding, ensuring the safety of road users while also protecting the road surface. ACO KerbDrain, a combined kerb and drainage system, is a versatile and efficient linear drainage solution suitable for various applications, including motorways, trunk roads, urban infrastructure, and landscaping projects.

Following on from the success of the KerbDrain D 400 range, ACO has expanded the portfolio to include new E 600 certified channels. KerbDrain E is designed for areas where kerbs are likely to recieve impact from heavy goods vehicles (HGVs) such as junctions and roundabouts while KerbDrain E+ addresses the demand for higher-capacity kerb drainage for large catchments areas. The award-winning one-piece design of KerbDrain makes it easy to install and provides high-impact performance for both traditional drainage systems and sustainable drainage schemes (SuDS).

Available sizes

The half battered profile channels are available in a range of different sizes ranging from 305mm to 480mm to meet hydraulic requirements.

Features

  • Impact resistance 50% higher than OPC kerb units
  • Manufactured from sustainable material
  • Available in half battered (HB) profile to BS EN 1340:2003
  • Capacity choices optimise hydraulic performance
  • One piece combined kerb and drainage system
  • Complies with IAN 117/08, Clause 516 SHW and is Kitemarked to BS EN 1433:2002 for highway use
  • Available in 305mm, 370mm and 480mm depths
  • ACO KerbDrain is fully certified to Load Class E 600 BS EN 1433:2002 and UKCA and CE marked

Benefits

  • Monolithic design enables faster installation than traditional two piece units
  • Larger capacity E+ channels available in the range for larger catchment areas
  • High impact resistance from HGV's
  • Seamless connection between KerbDain D, E and E+ channels via tranisiton units and gullies
  • Sealant groove for simple watertight installations
  • Safe manual and mechanical handling
  • Thermally stable, chemically resistant, environmentally friendly product manufactured from Vienite, ACO high strength sustainable material

Recommended Applications

  • Public landscaping
  • Junctions and roundabouts
  • Car parking
  • HGV parking
  • Petrol station forecourts
  • Light industrial
  • Heavy industrial
  • Public highways
  • Distribution yards
  • Security areas
  • SuDs

Not Recommended Applications

  • Threshold drainage
  • Airport (airside)
  • Domestic landscaping
  • Port and dock sides

Overview

KerbDrain E

  • One-piece combined kerb drainage system
  • Ideal for roundabouts and junctions
  • Kitemarked and certified to Load Class E 600
  • Can be combined with ACO KerbDrain D and E+ channels
  • Made from Vienite – ACO’s recycled material
  • Half battered kerb profile
  • Available in depths of 305mm and 480mm

KerbDrain E+

  • Monolithic channel construction
  • High-capacity units for large catchment areas
  • Kitemarked and certified to Load Class E 600
  • Connection to KerbDrain E units via gully unit
  • Made from Vienite – ACO’s recycled material
  • Half battered kerb profile
  • Available in depths of 370mm and 480mm

Featured Downloads

Login or register to download
KerbDrain E 600 Brochure
KerbDrain E 600 Brochure

Explore ACO KerbDrain E and E+ channel ranges for E 600 applications.

Download
The Route to Surface Water Management
The Route to Surface Water Management

Find out more about drainage design, maintenance, SuDS and biodiversity on Highways projects.

Download

Looking for a D 400 option?

KerbDrain D is the ideal solution for Highways projects which requires a combined kerb and drainage system, certifed up to Load Class D 400. The system benefits from an extensive range of problem-solving components including; perforated and flush centre stones, drop kerbs, radius and mitred units, internal angles, quadrants, and bus stop units. ACO KerbDrain D has a range of units to match HB1, HB2 and 45° splayed profiles, and a selection of depths and lengths to meet the hydraulic and performance requirements of many highways or drainage schemes.
